🛡️ How to Ingest Syslog and CEF Logs into Microsoft Sentinel Using Azure Monitor Agent (AMA)

Microsoft Sentinel enables security teams to collect, detect, investigate, and respond to security threats across hybrid and multi-cloud environments.
A crucial part of this capability is log collection — especially from Linux systems and network/security appliances that generate Syslog and CEF (Common Event Format) messages.

With the Azure Monitor Agent (AMA) and Data Collection Rules (DCR), Microsoft now provides a unified, modern way to onboard Syslog and CEF data into Sentinel — replacing the older Log Analytics (OMS) agent.

🔍 What Are Syslog and CEF?

🧩 Why Use AMA and DCR?

The Azure Monitor Agent (AMA) is the new unified agent for all Azure monitoring needs — performance, metrics, and logs.
It’s more efficient and flexible than the legacy agent and supports fine-grained control through Data Collection Rules (DCRs).

Benefits of AMA + DCR:

• ✅ Unified collection for Syslog, CEF, and performance metrics.
• ✅ Modern, scalable data pipeline managed through Azure Policy or Portal.
• ✅ Granular filtering: choose which facilities and severities to collect.
• ✅ Full support for Azure Arc–enabled servers (hybrid and on-prem).
• ✅ Automatic agent deployment and updates.

🏗️ Architecture Overview

Linux Servers / Security Devices
   ↓ (Syslog / CEF over TCP/UDP)
Azure Monitor Agent (AMA)
   ↓
Data Collection Rule (DCR)
   ↓
Log Analytics Workspace
   ↓
Microsoft Sentinel

• AMA – collects and forwards logs securely to Azure.
• DCR – defines what data to collect and where to send it.
• Workspace – stores logs for analytics and queries.
• Sentinel – correlates and visualizes data for detection and response.

⚙️ Prerequisites

Before configuring the connector:

1. 🧭 Log Analytics Workspace — Connected to your Sentinel instance.
2. 🧰 Azure Monitor Agent (AMA) — Automatically installed via DCR or manually.
3. 🌐 Outbound Internet Access — Port 443 to Azure Monitor endpoints.
4. ☁️ Azure Arc — Required if collecting from non-Azure Linux servers (e.g., RHEL).
5. 👩‍💻 Permissions — Owner, Contributor, or Security Admin on target machines.

🚀 Step-by-Step Setup (Portal Method)

Step 1 – Enable the Syslog/CEF Connector

1. Go to Microsoft Sentinel → Data connectors.
2. Search for “Syslog/CEF via AMA”.
3. Click Open connector page → Create data collection rule (DCR).

Step 2 – Configure the Data Collection Rule (DCR)

In the DCR wizard:

1. Choose your subscription, resource group, and region.
2. Select the machines to collect from (Arc-enabled or Azure VMs).
3. Define Syslog facilities (e.g., auth, authpriv, daemon, syslog, kern).
4. Select severities (e.g., Error, Critical, Alert, Warning, Info).
5. Set destination as your Log Analytics workspace.

💡 Tip: DCRs support multiple data types (Syslog, CEF, performance). You can reuse the same rule across servers.

Step 3 – Configure Syslog or CEF Forwarding on Linux

For RHEL or Ubuntu servers:

sudo vi /etc/rsyslog.d/60-sentinel.conf

Add the following lines:

# Listen for incoming CEF logs
module(load="imtcp")
input(type="imtcp" port="514")

# Optional: forward local logs to Sentinel
*.* @@127.0.0.1:514

Restart rsyslog:

sudo systemctl restart rsyslog

If using syslog-ng, configure a similar input block:

source s_net { tcp(port(514)); };
log { source(s_net); destination(d_logs); };

Step 4 – Send CEF Logs from Security Devices

For firewalls, IDS/IPS, or proxies:

• Configure the device to send CEF messages via Syslog (TCP 514) to the Linux forwarder VM.
• The forwarder then sends data to Sentinel via the Azure Monitor Agent.

Example:

Device → CEF message → rsyslog → AMA → Log Analytics → Sentinel

✅ Data arrives in the CommonSecurityLog table.

Step 5 – Verify Log Ingestion

Open the Sentinel workspace → Logs, and run:

Syslog check

Syslog
| take 10

CEF check

CommonSecurityLog
| take 10

If data appears, collection is successful 🎉

🧠 Troubleshooting Tips

🧾 Example Data Collection Rule (JSON)

Here’s a sample DCR that collects Syslog and CEF from RHEL:

{
  "location": "westeurope",
  "kind": "Linux",
  "properties": {
    "dataSources": {
      "syslog": [
        {
          "name": "syslog-source",
          "facilityNames": ["auth", "authpriv", "daemon", "syslog"],
          "logLevels": ["Error", "Critical", "Alert", "Emergency", "Warning"]
        }
      ]
    },
    "destinations": {
      "logAnalytics": [
        {
          "name": "la-destination",
          "workspaceResourceId": "/subscriptions/<sub>/resourceGroups/<rg>/providers/Microsoft.OperationalInsights/workspaces/<workspace>"
        }
      ]
    },
    "dataFlows": [
      {
        "streams": ["Microsoft-Syslog"],
        "destinations": ["la-destination"]
      }
    ]
  }
}

📊 Where Logs Appear in Sentinel

🔗 References

• Connect Syslog and CEF to Sentinel using AMA
• Syslog and CEF via AMA Overview
• Data Collection Rules (DCR)
• Azure Monitor Agent

🧩 Summary

✅ Use AMA + DCR for both Syslog and CEF ingestion
✅ Configure rsyslog/syslog-ng on your RHEL or collector VM
✅ Associate DCRs with Arc or Azure machines
✅ Validate in Syslog or CommonSecurityLog tables
✅ Retire the old Log Analytics (OMS) agent
