When you’re working with PaaS resources in Azure (for example: Azure Key Vault, Azure App Service, etc.), you often set their Diagnostic Settings to stream logs to an Azure Event Hubs namespace. The next step is: how to get that data into a Microsoft Sentinel-backed log analytics workspace for detection, hunting and alerts?

This article walks you through two supported Microsoft ways to ingest from Event Hubs into your log analytics/Sentinel workspace — one quick, one flexible — and provides updated details from Microsoft’s official docs.

---

🔍 Scenario Overview

• You have PaaS diagnostics streaming to an Event Hub (namespace/hub).
• You want to ingest those events into a Log Analytics workspace that supports Microsoft Sentinel.
• You prefer a path that is supported by Microsoft, scalable, and future-proof.

---

🅰️ Option 1 – Use Microsoft Sentinel’s “Azure Event Hubs” Data Connector

The fastest, minimal-code solution.

✅ Steps

1. In the Azure Portal, open your Microsoft Sentinel workspace.
2. Navigate to Configuration → Data connectors.
3. Search for “Azure Event Hubs” (or “Event Hubs” connector).
4. Click Open connector page → Connect.
5. Provide the Event Hub details:
   • Event Hub Namespace
   • Event Hub Name
   • Consumer Group (create a dedicated one for Sentinel)
6. Click Apply / Connect.
7. After setup, data from your Event Hub starts landing in your workspace (under a custom table, depending on connector).
   • Note: Sentinel handles the ingestion (behind the scenes) by deploying necessary Azure Function or service.
   • See Microsoft docs: Microsoft Sentinel data connectors Microsoft Learn+2Microsoft Learn+2

🧩 Pros & Cons

Pros:

• Very fast to set up.
• Minimal development/code effort.
• Built-in support in Sentinel’s connector catalogue.

Cons:

• Less control over schema/transformation of incoming data.
• You may not be able to fine-tune field mapping, filtering, or enrichment.
• If you have large volumes or custom formats, you might hit limitations.

📘 When to choose this

• For a proof of concept, quick ingestion.
• When you have relatively standard log formats and you just need them searchable in Sentinel.

---

🅱️ Option 2 – Use Azure Monitor Logs Ingestion via Data Collection Rule (DCR) + optional Data Collection Endpoint (DCE)

The more flexible, long-term solution, fully aligned with modern Azure Monitor architecture.

✅ Updated Steps (per Microsoft docs)

Based on the article “Ingest events from Azure Event Hubs into Azure Monitor Logs” Microsoft Learn

1. Ensure prerequisites:
   • Your Log Analytics workspace must have Contributor rights and be in the region you choose. Microsoft Learn
   • Your Event Hub namespace must allow public network access or allow “Trusted Microsoft Services” through firewall. Microsoft Learn
   • DCR and DCE (if used) must be in the same region as the Event Hub. The workspace can be any region, but DCR/DCE must match. Microsoft Learn
2. Create Destination Table in the Log Analytics workspace:
   • In your workspace → Logs → New table (or using the DCR transformation you configure).
   • This is where your Event Hub events will map. Microsoft Learn
3. Create Data Collection Endpoint (DCE) — optional but recommended for scale or private‐link scenarios:
   • In Azure Monitor → Data collection endpoints → Add.
   • Choose region, resource group, name.
4. Create Data Collection Rule (DCR):
   • In Azure Monitor → Data collection rules → Add.
   • In the rule:
     • Source: your Event Hub namespace & hub (connection string/consumer group).
     • Destination: Log Analytics workspace + target table.
     • Transformation: optional JSON parsing to reshape fields (map Event Hub message body to table columns).
   • Associate the DCR with the Event Hub. Microsoft Learn
5. Associate DCR with Event Hub:
   • Via the DCR UI or ARM template you specify the Event Hub resource.
   • After creation, ingestion begins.
6. Validate ingestion:
   • In Log Analytics workspace → Logs → query the destination table (e.g., MyCustomTable_CL | take 20)
   • Monitor ingestion latency, check for errors.

🧩 Pros & Cons

Pros:

• Full control over the incoming schema (transforms), filtering and mapping.
• Scale and performance aligned with Azure Monitor native ingestion.
• Supports advanced patterns (Private Link, multi‐region, enrichment).
• More future-proof for large enterprise workloads.

Cons:

• More setup effort (DCE, DCR, transformation JSON, permissions).
• Slightly steeper learning curve compared to built-in connector.

📘 When this is appropriate

• You have custom PaaS diagnostic schemas, need field mapping, or need to filter large volumes.
• You’re building a long-term logging architecture (not just a quick pilot).
• You expect to grow ingestion scale or apply strict cost/volume control.

---

🧭 Which Option Should You Choose? – Decision Table

Use Case	Recommended Option	Reason
Quick setup, standard logs, low volume	Option 1 – Sentinel Event Hub connector	Fastest path, minimal setup
Custom schema, high volume, long term, enrichment	Option 2 – DCR/DCE ingestion	Maximum flexibility and control
Mixed or evolving scenario	Start with Option 1, migrate to Option 2	Rapid lane then enterprise lane

---

💡 Best Practices & Additional Guidance

• Filtering & cost control: Ingesting everything without filter can incur high cost. Use transforms or diagnostic settings to limit what you send. Microsoft Learn+1
• Region alignment: For DCR/DCE ingestion, keep Event Hub, DCE, DCR in the same region to minimise latency. Workspace can be elsewhere but same-region is recommended. Microsoft Learn
• Consumer groups: For Event Hub ingestion, create a dedicated consumer group per ingestion path (Sentinel/DCR) to avoid interfering with other consumers.
• Permission & network: Ensure Event Hub namespace allows the ingestion service access (public network or “Allow trusted Microsoft services”) and that the workspace has required IAM roles. Microsoft Learn
• Schema versioning: If PaaS diagnostics change over time, use transformation logic to map new fields or gracefully degrade missing ones.
• Monitoring ingestion health: Use Azure Monitor metrics and logs to track ingestion latency, dropped events, size.
• Start small, then scale: Begin with a subset of logs (e.g., error-only) and then expand full diagnostic scope. This reduces initial cost and noise.

---

✅ Summary

• Two supported ingestion patterns:
  • Fast path: Sentinel connector (Event Hub)
  • Enterprise path: DCR/DCE ingestion via Azure Monitor Logs
• Use the right path based on your volume, schema complexity, and future growth.
• Follow Microsoft’s region/permissions requirements to avoid setup issues.
• Apply filtering, monitoring and best-practices to control cost and scale.
